Sustainable Energy Transition Progress in Recycling Precious Metals from Electrolysis Processes

Source: TU Bergakademie Freiberg Reading Time: 3 min

Related Vendors

For the past three years, a European research project has been investigating how to improve the recycling of precious metals such as platinum, iridium and ruthenium — which are used as catalysts in hydrogen electrolysis. Since these expensive metals cannot yet be completely replaced by other materials, the challenge is to recover them in a loss-free and environmentally friendly way.

Dr. Lesia Sandig-Predzymirska in the pilot plant. The research project is investigating environmentally friendly methods for recycling precious metals from electrocatalysts.
Dr. Lesia Sandig-Predzymirska in the pilot plant. The research project is investigating environmentally friendly methods for recycling precious metals from electrocatalysts.
(Source: TU Bergakademie Freiberg / C. Mokry)

Hydrogen from electrolysis with renewable energies is considered a key element of the energy transition. By means of catalysts, water is split into its components hydrogen and oxygen. The electrochemical reaction requires precious metals such as platinum, iridium or ruthenium as catalysts. How the recycling of these metals can be improved has been examined for three years by a European research project with the participation of TU Bergakademie Freiberg.

“Since the expensive precious metals in electrolysis cells cannot yet be completely replaced by other similarly efficient materials, the challenge is to recover them without loss. And this ideally with environmentally friendly processing,” explains project leader Prof. Alexandros Charitos fo TU Freiberg.

More Environmentally Friendly Processing of End-of-Life Catalyst Materials

The team focused on so-called hydrometallurgical recycling methods. This involves transferring the catalyst material into an aqueous solution and subsequently recovering it as a salt or metal in a solid form that is as pure as possible.

The recovery of the various catalyst layers from precious metals, the heart of the proton exchange membrane electrolyzer (PEM electrolyzer), has so far required an energy-intensive and potentially environmentally harmful process step. “In the Recycalyse project, we are pursuing a recycling process in which the catalyst layers are separated from the fluorine-containing membrane,” explains Dr. Lesia Sandig-Predzymirska. The precious metals in the pre-concentrated catalyst layers can then be recycled with milder and more environmentally friendly leaching agents. “This produces starting materials that can be used directly for the production of new electrocatalysts to close the material cycle,” says the researcher.

New Recycling Method for Precious Metal Ruthenium Patented

A newly developed catalyst made of iridium and ruthenium proved to be the most efficient for the oxygen evolution reaction on the anode side of the cell. An antimony-doped tin oxide acted as the support material for the metals instead of carbon. “We have developed and patented a hydrometallurgical process using low-cost chemicals to efficiently recover ruthenium complexes that are valuable to industry,” says Dr. Lesia Sandig- Predzymirska. Ruthenium complexes are not only used in the chemical industry for the production of catalysts, but are also used in many other fields such as the electronics industry, medicine, biology, nanoscience and solar cell production.

Together with a newly developed separation process of the individual metal ions, the team achieved a metal recovery of more than 90 percent of the contained precious metals.

Electrolysis in Focus of Research

As storage of hydrogen from water electrolysis is an important building block for the energy transition, electrode materials are currently in the focus of research. In addition to the efficiency and availability of the materials, the Recycalyse project focuses particularly on their recyclability in the sense of the circular economy. It is led by the Danish Technological Institute and supported by nine other partners (TU Bergakademie Freiberg, Fraunhofer ICT, Sustainable Innovations, TWI, Blue World Technologies, University of Bern, Prüfrex, Hycenta Research and Accurec). Until the end of September 2023, Recycalyse will be supported with a total of 5.5 million euros from the European Union's Horizon 2020 research and innovation program under grant agreement No. 861960.

Design of a PEM Electrolysis Cell

A thin membrane in the center of the PEM electrolytic cell is permeable to protons (H+), but prevents the transport of oxygen (O2) and hydrogen (H2). This membrane is coated with an anode catalyst and, opposite, a cathode catalyst. The layer consists of the catalyst on the support material mixed with an ion-conducting plastic (ionomer) for a uniform electrochemical reaction. As soon as an electrical voltage is applied to the electrodes, hydrogen is formed at the cathode and oxygen at the anode. First, water is added on the anode side, then the catalytic action of the noble metal catalyst causes the water to decompose. Oxygen (O2), electrons (e-) and protons (H+) are produced. The protons flow through the proton-conducting membrane to the cathode side, where they produce hydrogen with the electrons.
