Singapore: Direct Drug Delivery 'Contact Lens' Patch with Microneedles for Comfortable Drug Delivery
Nanyang Technological University, Singapore (NTU Singapore) scientists have developed a ‘contact lens’ patch with microneedles that could provide a painless and efficient alternative to current methods of treating eye diseases such as glaucoma and macular degeneration.
Singapore — Current localised treatment methods such as eye drops and ointments are hindered by the eye’s natural defences, blinking and tears. Eye injections can be painful and carry a risk of infection and eye damage. As a result, some patients are unable to keep up with the prescribed regime for their eye ailments, many of which require long-term management.
The proof-of-concept patch, successfully tested in mice, is covered with biodegradable microneedles that deliver drugs into the eye in a controlled release. After pressing it onto the eye surface briefly and gently — much like putting on contact lenses – the drug-containing microneedles detach by themselves and stay in the cornea, releasing the drug over time as they dissolve.
When tested on mice with corneal vascularisation, a single application of the patch was 90 % more effective in alleviating the condition than applying a single eye drop with 10 times more drug content. This novel approach, developed by a team led by NTU Singapore Professor Chen Peng from the School of Chemical and Biomedical Engineering (SCBE), with clinical insights from Singapore National Eye Centre’s Associate Professor Gemmy Cheung, was published in Nature Communications earlier this month.
Minimally Invasive Treatment
Professor Chen, the biotechnology expert who also developed the fat-burning microneedle patch, said this approach could realise the unmet medical need for a localised, long-lasting and efficient eye drug delivery with good patient compliance. The microneedles are made of a substance found naturally in the body, and the scientists have shown in lab tests on mice that they are painless and minimally invasive. If they successfully replicate the same results in human trials, the patch could become a good option for eye diseases that require long-term management at home, such as glaucoma and diabetic retinopathy.
Patients who find it hard to keep up with the regime of repeatedly applying eye drops and ointments would also find the patch useful as well, as it has the potential to achieve the same therapeutic effect with a smaller and less frequent dosage. Prof. Chen added that the patch could also help to tackle the rising disease burden of eye conditions. A local 2018 study projected that patients with eye diseases in Singapore will rise significantly by 2040, with glaucoma, diabetic retinopathy and age-related macular degeneration cases set to double.
Novel Approach in Treating Eye Diseases
Currently, localised treatment options are hampered by the eye’s physiological and structural barriers, including blinking and tears that wash out any drugs applied directly to the eye’s surface.
Topical drugs such as eye drops and ointments require repetitive applications with high dosage as less than 5 % of the drug is absorbed by the eye each time, and the drug is quickly cleared out by the eye.
Conventional eye injections can penetrate the surface barriers, but face the same problem or poor drug retention due to the backflow of injected solution and subsequent tear wash-out. Aside from carrying a risk of infection or permanent eye damage, patient compliance is poor due to pain and the need for frequent clinic visits. Prof. Chen added that these two current methods only produced a burst release of drug with a short effective duration. This was not ideal, especially when treating chronic progressive eye diseases that require slow and sustained treatment, such as glaucoma.
To tackle these problems, the team developed a 2 mm by 2 mm patch with nine microneedles that can be loaded with drugs for lab tests. Each needle, thinner than a strand of hair, is shaped like a pyramid for optimal tissue penetration. The needle is made of hyaluronic acid, a substance found in the eye and is used often in eye drops. A modified version of the hyaluronic acid is added to form a second layer of the needle to slow down the rate at which the needle degrades, ensuring a slower release of the drug.
Dr. Aung Than, NTU research fellow at SCBE, then planned and conducted experiments over a week on mice with corneal vascularisation, a sight-threatening condition where new blood vessels grow into the corneal tissue due to oxygen deprivation. In this study, the researchers loaded the microneedles with DC101, an antibody that targets the growth factor that promotes blood vessel formation.
In mice with the patches applied, there was a 90 %reduction in the area of blood vessels with a single treatment dose of 1 microgram. In contrast, when a single drop of the same drug with a much higher dose of 10 micrograms was applied, there was no significant reduction. There was also no puncture found on the cornea after a week, suggesting that the microneedles are strong enough to penetrate the cornea, but not too stiff to spear through the whole cornea.
Prof. Chen said the team has filed a patent, and is currently working on further improving the eye patch technology. They are also looking to partner clinician scientists to study the feasibility of conducting medical trials.
