Unique Solution Introducing a New Material that Can Reduce Energy Consumption in Electronics

Researchers have developed a unique material that has the potential to consume less energy and at the same time generate more computing power and memory storage in computers and electronics.

Minnesota/USA – A University of Minnesota team has, for the first time, synthesized a thin film of a unique topological semimetal material that has the potential to generate more computing power and memory storage while using significantly less energy. The researchers were also able to closely study the material, leading to some important findings about the physics behind its unique properties.

The study is published in Nature Communications.

As evidenced by the United States’ recent Chips and Science Act, there is a growing need to increase semiconductor manufacturing and support research that goes into developing the materials that power electronic devices everywhere. While traditional semiconductors are the technology behind most of today’s computer chips, scientists and engineers are always looking for new materials that can generate more power with less energy to make electronics better, smaller and more efficient.

One such candidate for these new and improved computer chips is a class of quantum materials called topological semimetals. The electrons in these materials behave in different ways, giving the materials unique properties that typical insulators and metals used in electronic devices do not have. For this reason, they are being explored for use in spintronic devices, an alternative to traditional semiconductor devices that leverage the spin of electrons rather than the electrical charge to store data and process information.

In this new study, an interdisciplinary team of University of Minnesota researchers were able to successfully synthesize such a material as a thin film — and prove that it has the potential for high performance with low energy consumption.

“This research shows that you can transition from a weak topological insulator to a topological semimetal using a magnetic doping strategy,” said Jian-Ping Wang, a senior author of the paper and a professor in the College of Science and Engineering. “We’re looking for ways to extend the lifetimes for our electrical devices and at the same time lower the energy consumption, and we’re trying to do that in non-traditional, out-of-the-box ways.”

Researchers have been working on topological materials for years, but the U of M team is the first to use a patented, industry-compatible sputtering process to create this semimetal in a thin film format. Because their process is industry compatible, Wang said, the technology can be more easily adopted and used for manufacturing real-world devices.

“Every day we use electronic devices, from our cell phones to dishwashers to microwaves. They all use chips. Everything consumes energy,” said Andre Mkhoyan, a senior author of the paper and professor in the College of Science and Engineering. “The question is, how do we minimize that energy consumption? This research is a step in that direction. We are coming up with a new class of materials with similar or often better performance, but using much less energy.”

Because the researchers fabricated such a high-quality material, they were also able to closely analyze its properties and what makes it so unique.

“One of the main contributions of this work from a physics point of view is that we were able to study some of this material’s most fundamental properties,” said Tony Low, a senior author of the paper and an associate professor in the College of Science and Engineering. “Normally, when you apply a magnetic field, the longitudinal resistance of a material will increase, but in this particular topological material, we have predicted that it would decrease. We were able to corroborate our theory to the measured transport data and confirm that there is indeed a negative resistance.”

Low, Mkhoyan, and Wang have been working together for more than a decade on topological materials for next generation electronic devices and systems — this research wouldn’t have been possible without combining their respective expertise in theory and computation, material growth and characterization, and device fabrication.

“It not only takes an inspiring vision but also great patience across the four disciplines and a dedicated group of team members to work on such an important but challenging topic, which will potentially enable the transition of the technology from lab to industry,” Wang said.

This research is supported by Smart, one of seven centers of ncore, a Semiconductor Research Corporation program, sponsored by National Institute of Standards and Technology. T.P. and D.Z. were partly supported by Ascent, one of the six centers of Jump, a Semiconductor Research Corporation program that is sponsored by Marco and Darpa. This work was partially supported by the University of Minnesota’s Materials Research Science and Engineering Center program. Parts of this work were carried out in the Characterization Facility of the University of Minnesota Twin Cities, which receives partial support from the National Science Foundation through the MRSEC. Portions of this work were conducted in the Minnesota Nano Center, which is supported by the NSF Nano Coordinated Infrastructure Network.
