UK: Photonics How Record-Breaking Strain in Single-Crystal Silicon Could Lead to Smoke-Detecting Phones

The introduction of strain into semiconductors offers a well-known route to modify their band structure. Researchers at the University of Surrey showed a single-step procedure for generating such strains smoothly and deterministically, over a very wide range, using a simple, easily available, highly scalable, ion implantation technique to control the degree of amorphization in and around single-crystal membranes.

Surrey/UK — A discovery made at the University of Surrey could be crucial to the future development of silicon photonics, which underpins the technologies behind the internet-of-things, and is currently constrained by the lack of cheap, efficient, and easily integrated optical emitters.

The scientists were able to develop a single-step procedure to put single-crystal silicon under more strain than has been achieved before. Now, the researchers are transferring the same procedure to germanium. If successful, they will open the door to creating germanium lasers, which are compatible with silicon-based computers, and could revolutionise communications systems by means of new opto-electronic devices. This would address the problem of overheating, which is becoming a threat to development in silicon-based computer systems, and would eliminate the need to develop expensive and difficult to integrate III-V devices, a popular area of research to try to overcome overheating.

Moving photonics fully onto silicon has been a long-held goal, and while there have been many successes in developing passive silicon photonic devices, a laser that is CMOS-industry compatible, using elements from the same group of the periodic table, has remained elusive until now. The team were recently awarded an EPSRC New Horizons project grant to exploit their innovation and progress their work.

The new approach is also an important step towards creating near-infrared sensors that could pave the way towards developing more sophisticated smartphones – fitting them with fire alarms and carbon monoxide sensors.

A new paper published in the Physical Review Materials journal describes how the team generated strain via ion implantation in suspended membranes in a similar manner to tightening a drum skin. The effect is created by a downward bowing of the implanted region because of a still crystalline layer underneath the implanted top region in a mechanism analogous to a bi-metallic strip submitted to a temperature change.

The team from the University of Surrey's Advanced Technology Institute and Department of Physics demonstrate that up to 3.1 percent biaxial strain and up to 8.5 percent uniaxial strain can be generated but point the way to even larger strains, achievable by varying the implant species and by exploiting the underlying crystal direction.

The method far exceeds previous records using more complex approaches. In the Group-IV semiconductor germanium, an indirect-to-direct transition in the electronic bandgap occurs at much lower strains than silicon, where this new method offers huge potential.

Although the procedure is relatively simple and points the way to a versatile, fast, generally applicable, and widely available technique for strain control, its development required the use of two national facilities: the Surrey Ion Beam Centre, which allows users to undertake a wide variety of research using ion implantation, ion irradiation and ion beam analysis, and which also has extensive processing and characterisation facilities; and the National Physical Laboratory, the UK's National Metrology Institute, which develops and maintains national primary measurement standards and which ensures cutting-edge measurement science has a positive impact in the real world.

Original Source: DOI: https://doi.org/10.1103/PhysRevMaterials.5.124603
